Nano Scale Gradual Coating Brine Electrolysis Sodium Hypochlorite For Water Treatment

Nano Scale Gradual Coating Brine Electrolysis Sodium Hypochlorite For Water Treatment

    • Nano Scale Gradual Coating Brine Electrolysis Sodium Hypochlorite For Water Treatment
    • Nano Scale Gradual Coating Brine Electrolysis Sodium Hypochlorite For Water Treatment
    • Nano Scale Gradual Coating Brine Electrolysis Sodium Hypochlorite For Water Treatment
  • Nano Scale Gradual Coating Brine Electrolysis Sodium Hypochlorite For Water Treatment

    Product Details:

    Place of Origin: CHINA
    Brand Name: CNJS
    Certification: ISO9001
    Model Number: CNJS-L-5000

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 SET
    Price: NEGOTIATION
    Packaging Details: wooden case
    Delivery Time: 20-45 wok days
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 20 sets per month
    Detailed Product Description



    Nano Scale Gradual Coating Brine Electrolysis Sodium Hypochlorite For Water Treatment





    Principle:



        CNJS - L series NaClO generator is a new type of NaClO solution for field production equipment , suitable for all kinds of needs NaClO disinfected venues. Its working principle is:

      the sodium chloride solution under the certain voltage effect of the cell, a series of electrochemical reaction within the cell and the resulting solution is the NaClO solution. The main process can be simplified as follows:

    Electrode reaction:

    anode:2Cl--2e→Cl2

    cathode:2H++2e→H2

    Solution:2NaOH+Cl2→NaCl+NaClO+H2O




    Technical parameters:



    Type

    Power(V/Hz)

    concentration of liquid(mg/l)

    available chlorine (Kg/h)

    Flow (m3/h)

    Salt consumption (kg/d)

    Water consumption (m3/d)

    Power consumption   (kw)

    Size(m)      (l×w×h)

    CNJS-L5000

    380V/50Hz

    7-9

    5

    0.5

    336

    12

    20

    1200*860*1950





    Work flow chart :

    Nano Scale Gradual Coating Brine Electrolysis Sodium Hypochlorite For Water Treatment



    Automatic sodium hypochlorite generator system fully automatic production, contains the system



    A, Automatic dissolving salt tank :Including salt tank , liquid level control , dissolving salt pump , electric valves , piping and other components which could automatic transmission salt , dissolving salt , saturated brine

    B, Saturated brine filter :Including stainless steel two precision filter ,primary filtering accuracy 50um, secondary filtration precision 5um, use PP filter , the filter can be easily replaced, ensure clean brine ;

    C, Dilute brine tank :The saturated brine and production water has been diluted with 2.5 % weak brine water , for the power solutions

    D, Sodium hypochlorite generator host machine :Including electrolytic cell , electrolysis power , intelligent control center PLC , the control element, man-machine interface , PC communication module, the operator panel, the host stand, electric valves, electrical power distribution system

    E, Sodium hypochlorite solution storage tank :including hydrogen storage tank , exhaust equipment

    F, Automatic dosing and on-line monitoring system: including the inverter , corrosion metering dosing pump , online residual chlorine monitor , and the closed-loop control of chlorine

    G, Online instrument series : Production water pressure monitoring , dilute brine online salinity monitoring , temperature controller , flammable gas monitoring sensor , these monitoring instruments are all included alarm signal output





    Advantage of on-site sodium hypochlorite generator



    Compared with other brand



    CNJS Technology

    other brand

    Advantages of CNJS

    Appearance

    CNJY Y1000 on-site sodium hypochlorite generation split type multifunctional

    CNJY Y1000 on-site sodium hypochlorite generation split type multifunctional

    Other equipment framework will rust after three months and  three years later, will affect the service life of equipment. CNJY equipment framework use alumina material, and does not rust



    Space

    Host machine size:1200*860*1950

    Host machine :2000*1000*2200              Control cabinet:850*700*1800          rectifier:500*1000*1100                 Host machine , Control cabinet , rectifier can not put in one rom together , need anther device room

    saving space Easy to install and operate

    Raw material

    refined salt or Industrial salt

    refined salt

    A wide scope of utility, economy and low operating cost

    Inlet water requirements

    Depend on actual situation need a water softener or not

     indispensable a water softener

    Can reduce unnecessary link,  increase equipment safety.

    Dilute brine ratio

     water injector ratio

     normal valve

    High accuracy, more safety

    Thickness of electrodes

    2mm

    1.5mm

    Long life of electrode, resistance to deformation, not short-circuited.

    Electrode coating technology

    nano- coated up to 20 ruthenium iridium oxide particles , coating thickness of 2- microns , 25 times of coating can ensure positive side high produ ing and long life

    Normal ruthenium iridium thickness thin, easy to deformation.

    Coating adhesion, long service life

    Electrode gap

    Big gap and flux

    Small gap and flux

    Low temperature big flux  equipment, high efficiency.

    H2 discharge

    Two gradually exhaust, install the detector

    One way,Rising concentrations in tube and  not safe


    More secure.

    Dosing accuracy

    Multilayer additive form, adding the high precision

    Quantitative dosing, water data is not stable

    Water stable,long service life

    Intelligent control

    Truly intelligent, fully integrated modular structure

    Distributed assembly, intelligent poor

    High performance and stability

    Power system

    Using marine-grade high-frequency voltage constant current power supply, low heat, stable and integrated and equipment

    SCR ballast, large energy consumption, no security, occupy  space, poor stability

    Low power consumption, covers an area of small, low malfunction

    Pickling process

    Small devices not pickling, large equipment protection pickling mobile devices

    Small equipment to pickling, large equipment pickling less protection

    Free of acid pickling, more stable, more safe.

    The man-machine interface

    Small devices with Siemens touch screen, large equipment with industrial man-machine interface

    Small equipment without man- machine interface, large equipment with normal interface

    Convenient and easy to use

    The PLC program

    All size equipment configuration of the PLC, unattended and intelligent control.

    Small equipment without PLC, often appear effluent water  not stable

    Suitable for anyone, no need  professionals.

    Security

    Fully enclosed structure, high stability and high safety of the equipment

    All the equipment and instruments outside naked, fragile and aging

    Easy installation, long service life

    Service life

    More than 8 years

    Less than 5 years

    Warranty time

    15 years

    10 years















    Details :

    Nano Scale Gradual Coating Brine Electrolysis Sodium Hypochlorite For Water Treatment

    CNJS Technology : Full framework of alumina , corrosion resistance,

    Compressive strength , impact resistance

    Never rust , design life for more than 50 years







    Nano Scale Gradual Coating Brine Electrolysis Sodium Hypochlorite For Water Treatment

    Other brand :

     Full channel structure , no corrosion , easy to deformation and rust , after half year the framework like above figure , the useful life is  only three years.





                                           Nano Scale Gradual Coating Brine Electrolysis Sodium Hypochlorite For Water TreatmentNano Scale Gradual Coating Brine Electrolysis Sodium Hypochlorite For Water Treatment
