IS9001 Sodium Hypochlorite Water Treatment 200G Active Chlorine For Disinfection

IS9001 Sodium Hypochlorite Water Treatment 200G Active Chlorine For Disinfection

    • IS9001 Sodium Hypochlorite Water Treatment 200G Active Chlorine For Disinfection
    • IS9001 Sodium Hypochlorite Water Treatment 200G Active Chlorine For Disinfection
    • IS9001 Sodium Hypochlorite Water Treatment 200G Active Chlorine For Disinfection
  • IS9001 Sodium Hypochlorite Water Treatment 200G Active Chlorine For Disinfection

    Product Details:

    Place of Origin: CHINA
    Brand Name: CNJS
    Certification: ISO9001
    Model Number: CNJS-S

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 SET
    Price: NEGOTIATION
    Packaging Details: wooden case
    Delivery Time: 7-15 work days
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 100 SETS /month
    Detailed Product Description
    Available Chlorine: 7.0-9.0 G / L Power Input: 220V, 50Hz
    Inlet Water Temperature: 5-27鈩 Inlet Water Pressure: 0.2-0.4Mpa
    Salt Consumption: 3.5kg/kg Cl2 Water Consumption: 125L/kg Cl2
    Electrolytic Liquid: 2.5~3% Weak Brine Content Available CL: 7000~9000ppm
    Rated Current: Determined According To The Selected Product Model

    IS9001 Approval Sodium Hypochlorite Generator 200G Active Chlorine For Disinfection


    Technical parameters:

    Type

    Av.CL2 Capacity
     (g/h)

    Flow Rate
     (L/h)

    Salt Consumption
     (kg/d)

    Water
    Consumption
    (m3/d)

    Rated power
     (kw )

    Unite size
     (L×W×H)
    (mm)

    CNJS-S-100

    100

    13

    8.4

    0.31

    0.6

    1200×800×1400

    CNJS-S-200

    200

    25

    16.8

    0.6

    1.2

    1200×800×1400

    CNJS-S-300

    300

    38

    25.2

    0.91

    1.8

    1200×800×1400

    CNJS-S-400

    400

    50

    33.6

    1.2

    2.4

    1200×800×1400

    CNJS-S-500

    500

    63

    42

    1.51

    3

    1200×800×1400


    Note:System requirements with salt and water


    Salt requirements:



    Name

    Request content( %)

    (NaCl)

    >99.3 %

    (Fe)

    <0.002%

    (Ca Mg)

    <0.023%

    (Mn)

    <0.00003%

    (Pb)

    <0.0007%

    (Cu)

    <0.0003%

    (F)

    <0.01%



    Water requirements:
    1)Operating water temperature:
    The temperature between (18藲C-23藲C)is best. If do not use temperature regulation, please allow the temperature between (10藲C-27藲C),or a heating exchanger or chiller equipment to be used for adjust the water temperature.
    2)Operating water pressure:
    Minimum 0.2 MPa, Maximum 0.35 Mpa, if not in this scope, need to increase a he pressure or vacuum equipment
    3)water quality requirements:
    pH 6.5 to 8.5
    hardness[in calcium carbonate] < 5 ppm (soft water equipment outlet)
    COD(Mn) < 1.5 ppm
    Fe < 0.2  ppm
    Mn < 0.01 ppm
    Ni < 5 ppm
    F <2 ppm
    Cu < 5 ppb



    Product introduction:

    Generation principle:

        The revolutionary CNJS-S series sodium hypochlorite generator is a newly and for on-site product of NaClO equipment and use for all kinds of needed NaClO disinfected. Its working principle is :the sodium chloride solution under the certain voltage effect of the cell, a series of electrochemical reaction within the cell and the resulting solution is the NaClO solution. The main process can be simplified as follows:

    IS9001 Sodium Hypochlorite Water Treatment 200G Active Chlorine For Disinfection
    The electrode reaction:
    anode:2Cl--2e→Cl2
    cathode:2H++2e→H2
    solution:2NaOH+Cl2→NaCl+NaClO+H2O

    Work flow chart:


    IS9001 Sodium Hypochlorite Water Treatment 200G Active Chlorine For Disinfection
    Product components system

    A,inlet water distribution system
    Main components: water pressure gauge, water softener, soft water pump, water meter, salt tank, salt water pump and related piping and valves.


    B,The power control system:
    Including control cabinet, rectifier and cable connection.



    C,Storage and dosing system
    Including electrolytic cell, NaClO tank, dosing pump, piping and valves.




    Advantage of on-site sodium hypochlorite generator

    SAFETY:
    Material safety: Salt, Water and Electricity as raw materials, no need for transportation of dangerous chemicals;
    Process safety: No risk of chlorine leakage and reactor explosion, safety for operator;
    Product safety: Product-0.8% NaCIO solution, has the advantage of stable and safety, cost effective in operation and no attenuation in storage.
    ENERGY-SAVING:
    Make use of electricity in the off-peak period to generate the NaCIO solution.
    ENVIRONMENTAL PROTECTION:
    Avoid of usage, transportation of dangerous chemical material.
    High current efficiency ,few by-product, safe H2 ventilation.
    ECONOMY:
    JIASHANG equipment can largely reduce the operation cost compared to the bulk hypochlorite


    TAG:

    Sodium hypochlorite generator, On-site sodium hypochlorite





    DETAILS:



    IS9001 Sodium Hypochlorite Water Treatment 200G Active Chlorine For Disinfection


    IS9001 Sodium Hypochlorite Water Treatment 200G Active Chlorine For Disinfection
