Steel Plants Sodium Hypochlorite Generator With 2000-3000mg/L Concentration

Steel Plants Sodium Hypochlorite Generator With 2000-3000mg/L Concentration

    • Steel Plants Sodium Hypochlorite Generator With 2000-3000mg/L Concentration
    • Steel Plants Sodium Hypochlorite Generator With 2000-3000mg/L Concentration
  • Steel Plants Sodium Hypochlorite Generator With 2000-3000mg/L Concentration

    Product Details:

    Place of Origin: CHINA
    Brand Name: CNJS
    Certification: ISO9001
    Model Number: CNJS-SW15

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 SET
    Price: NEGOTIATION
    Packaging Details: wooden case
    Delivery Time: 20-45 work days
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 20 SETS PER MONTH
    Detailed Product Description
    Inlet Water Temperature :: 5 聞 辖 + 35 聞冿紱 Inlet Water Pressure :: 0.2 ~ 0.4 Mpa 霞
    Water Consumption :: According To The Local Water Conditions 霞 The Electrolyte Temperature Rise:: <5 聞 霞
    Concentration: 2000-3000mg/L Electrode Cell: Bipolar
    Electrode Life: Moren Than Five Years Electrolysis Solution: Sea Water

    Onsite sodium Hypochlorite Generator From Seawater Electrolysis







    Steel Plants Sodium Hypochlorite Generator With 2000-3000mg/L Concentration





    Technical parameters:



    Type

    Power(V/Hz)

    available chlorine (Kg/h)

    Flow (m3/h)

    Power consumption   (kw)

    Size(m)      (l×w×h)

    CNJS-SW15

    380V/50Hz

    15

    2.5

    75

    900*600*1500





    Product system:

    1. Automatic dissolving salt tank :Including Seawater lift pump, filter device
    2. Sodium hypochlorite generator host machine :Including electrolytic cell , electrolysis power , intelligent control center PLC , the control element, man-machine interface , PC communication module, the operator panel, the host stand, electric valves, electrical power distribution system
    3. Sodium hypochlorite solution storage tank :including hydrogen storage tank , exhaust equipment
    4. Automatic dosing and on-line monitoring system: including the inverter , corrosion metering dosing pump , online residual chlorine monitor , and the closed-loop control of chlorine
    5.
    Online instrument series : Production water pressure monitoring , dilute brine online salinity monitoring , temperature controller , flammable gas monitoring sensor , these monitoring instruments are all included alarm signal output



    • Application :
    • Extensive use of seawater as cooling water such as: petroleum chemical plants, steel plants, thermal power stations and other coastal and marine plants.
    • Seawater as raw material can simply generate the required amount of sodium hypochlorite. Water electrolysis device can applied in many areas. And also in the field of water treatment oxidation and disinfection by sodium hypochlorite.





    workshop :

    Steel Plants Sodium Hypochlorite Generator With 2000-3000mg/L Concentration
